Electroformed grating

Electroformed grating is a precision optical component fabricated via electroforming. Featuring uniform periodic microstructures, it delivers high reflectivity and excellent dimensional stability. Widely used for light diffraction and spectral splitting, it serves optical encoders, spectrometers and laser systems. Custom line density and sizes are available to meet your metrology and optical measurement requirements.

CONSULTATION

189-3869-3452 0513-8160 1666

PRODUCT DETAILS

Electroformed Grating: High-Precision Custom Metal Grating for Industrial & Optical Applications

Electroformed grating is a high-precision metal functional component manufactured through professional electroforming technology, widely recognized as a core precision part in optical detection, industrial automation, new energy equipment and precision instrumentation industries. Different from traditional stamping and welded gratings, electroformed grating features ultra-high dimensional accuracy, uniform grid structure, excellent surface flatness and stable mechanical performance, making it the preferred solution for high-end precision grating scenarios worldwide. As a professional manufacturer focusing on high-quality electroformed grating, Nantong Zhuolida provides customized, high-durability grating products for global industrial and optical customers.

The unique manufacturing process is the core advantage of electroformed grating. The whole production relies on mature electroforming technology, which uses metal electrodeposition to form an integrated grating structure without secondary welding, stamping or cutting processing. This integral forming process effectively avoids structural deformation, grid dislocation and stress concentration problems common in traditional grating products. The precision of electroformed grating can reach micron level, with consistent grid spacing, uniform hole shape and ultra-smooth surface without burrs, fully meeting the strict precision requirements of high-precision optical testing and industrial precision transmission.

In terms of material and performance, custom electroformed grating produced by Nantong Zhuolida adopts high-purity metal materials such as nickel and nickel alloy, with hardness up to HV500-700. The product has outstanding wear resistance, corrosion resistance and high-temperature resistance, adapting to extreme working environments ranging from -40℃ to 150℃. It can withstand 50G strong impact and long-term vibration friction, with a service life of more than 10 million operating cycles. In industrial scenarios with oil pollution, dust and frequent mechanical movement, electroformed grating can maintain stable structural accuracy and will not deform or fail due to harsh working conditions, greatly reducing equipment maintenance and replacement costs for customers.

电铸光栅

Electroformed grating has extremely wide application coverage, covering multiple high-precision industries. In the optical industry, it serves as a key core component of optical measuring instruments, microscopes, telescopes and spectral analysis equipment, used for optical signal splitting, filtering and precision positioning, ensuring high-precision detection and imaging effects. In the communication field, electroformed grating acts as an important grating coupler and filter component in optical fiber communication systems, stabilizing signal transmission efficiency and improving communication accuracy.

In industrial automation and new energy fields, high-precision electroformed grating is widely applied in CNC machine tools, industrial robots, new energy vehicle servo systems and precision encoding equipment. Its precise grid spacing ensures accurate signal induction and position feedback, improving the overall operating precision and stability of automated equipment. In addition, customized electroformed gratings with special pore shapes and sizes can be developed according to customer’s special equipment parameters, realizing one-stop personalized matching for different industrial and optical equipment.

Compared with ordinary steel gratings and stamped gratings, electroformed grating has irreplaceable competitive advantages. Traditional gratings are limited by processing technology, with low precision, poor consistency and easy deformation, which cannot meet the needs of high-end precision equipment. While electroformed grating achieves integrated integral molding, with zero error in batch production, excellent product consistency and strong design flexibility. It can support ultra-thin, ultra-fine, special-shaped grid customization, and can realize mass stable production of complex structural gratings, balancing high precision and mass production efficiency.

As a reliable global supplier of electroformed grating, Nantong Zhuolida has mature electroforming production technology, complete production equipment and strict quality inspection system. All electroformed grating products are strictly tested in terms of dimensional accuracy, surface flatness, mechanical strength and corrosion resistance before delivery, with stable product quality and high batch consistency. We support global OEM and ODM customization services, provide professional technical consultation and personalized solution design according to customer drawings, parameters and application scenarios, and deliver high-cost-performance precision electroformed grating products for global customers.

In conclusion, with the upgrading of global precision manufacturing and optical technology, high-precision electroformed grating has become an indispensable core component in high-end manufacturing fields. With superior precision, stable performance, strong durability and flexible customization advantages, it has gradually replaced traditional grating products and occupied the mainstream market of high-precision grating components. For customers who need high-quality, high-precision and long-service-life grating components, customized electroformed grating from Nantong Zhuolida is your most trustworthy choice.
