Molybdenum reseau

Molybdenum reseau is mainly used in traveling wave tube, transmission electron microscope, electron microscope, electron gun at low temperature, etc.Microwave vacuum electronic device in some military electronic equipment plays a key role, most of the electron gun of microwave tube are adopted near the cathode surface to one or more of the molybdenum reseau to control current

CONSULTATION

86-513-81601668 86-18206293159

PRODUCT DETAILS

Product introduction
Product introduction:	Molybdenum reseau
Product description:	In recent years, with the rapid development of electronic technology, molybdenum has been widely used in electron tubes, transistors and rectifiers.It is an important part of electronic warfare and modern military equipment, and has recently received increasing attention, as well as strict selection of raw materials.
Product usage:	Molybdenum reseau is mainly used in traveling wave tube, transmission electron microscope, electron microscope, electron gun at low temperature, etc.Microwave vacuum electronic device in some military electronic equipment plays a key role, most of the electron gun of microwave tube are adopted near the cathode surface to one or more of the molybdenum reseau to control current.
Etching process:	Material opening → cleaning plate → dry film or coating → drying → exposure → development → drying → etching → stripping → detection of packaging -- finished product shipment.
Our strengths
1. Till 2018, we have been engaged in the field of etching for 19 years, and have been committed to technical innovation, research and development, production and sales of molybdenum grid products in the middle and high-end market.Aspire to become China's etching industry hundred year enterprise!
2. The company has successively passed iso9001:2008 quality management certification and iso14001:2004 environmental management system. In 2016, the company passed ISO/TS 16949 certification and high-tech enterprise certification.
3. As a member of PCMI, the world etching association, the company can share new information and equipment of the global etching industry.
4. It has an automatic adding system and regeneration system for potions, and a self-built large-scale sewage treatment system, with the reuse rate of wastewater reaching above 40%.
5. We can make molybdenum mesh with a small thickness of 0.02mm and a large etching size of 1800*700mm, with a precision up to +/-0.005mm according to the product.
6. Shenzhen zhulida, kunshan zhulida and nantong zhulida three production bases, with a comprehensive area of more than 40,000 square meters.More than 20 conventional, imported and customized non-standard precision etched lines can meet the production capacity and accuracy requirements of various molybdenum mesh.

PRODUCT CHARACTERISTICS

01
Because of molybdenum is a kind of refractory metal melting point is 2625 degrees, it has the very strong tensile strength at high temperature, the creep strength and good heat resistance, low thermal expansion coefficient, high thermal conductivity and electrical conductivity, and on the liquid metal, potassium, calcium, bismuth and cesium and other molten salt has good corrosion resistance, therefore, its application in various forms in the national economy each domain, such as aerospace and nuclear energy, lighting appliances and electronics, vacuum furnace and protective atmosphere furnace, metal pressure processing, glass industry, etc.
02
Because grid control can make the modulator very small, so it has been very widely used and popularized.In order to obtain a lower gate by the voltage, small spacing between grid wire must, in order to reduce the current intercepted reseau, the area of the wire grid and the ratio of the cathode area must be smaller, because of reseau near hot cathode, high working temperature anomalies, so the reseau usually adopt good high temperature strength, to escape the power of molybdenum materials, collectively known as molybdenum reseau in the industry.

The application of molybdenum grid is more and more extensive, thus arises at the right moment the molybdenum grid processing factory is more and more.But molybdenum material is relatively fragile material and extremely hard, with stamping and wire cutting can not be processed, the current molybdenum products processing methods are using chemical corrosion technology to complete.Zhuolida service nationwide molybdenum grid customers, if you want to find molybdenum grid manufacturers, please contact us zhuolida company, the company will serve you wholeheartedly!
